Optisan EVX G2 4-16x44 F1 FFP Non Illuminated MRAD Scope

DESCRIPTION

Optisan Optics EVX G2 4-16x44 F1 Non Illuminated MRAD16 Side Focus 0.1 MRAD LT Rifle Scope

Brand new to the Optisan range of optics is highly anticipated Optisan EVX G2 4-16x44 FFP , this eagerly awaited replacement for the discontinued EVX G1 has finally arrived. The Optisan EVX G2 4-16x44 F1 comes with a first focal plane milradian based non illuminated MRAD16 reticle. This simple yet effective reticle features a series of hash marks from the center cross from 1 MRAD to 15 MRAD quick hold over 0.1 and 0.05 MRAD mil-dots that offer quick hold points for windage calls and windage hold offs. These dots start from the 1 MRAD has mark and move out across the windage in 1 MIL increments in a XMAS tree fashion until reaching the 5 MRAD hash marking on the elevation.

The Optisan EVX G2 4-16x44 F1 has a 30mm tube that provides 20.4 MRAD of internal adjustment and 0.1 MRAD turrets which are lockable ensuring the user cannot accidententally knock these in the field or while transporting their firearm. The Optisan EVX G2 4-16x44 FFP has an improved optical system which helps provide the shooter with better optical clarity and resolution. This versatile rifle scope is perfect for air rifle shooters and centerfire shooters; its an ideal choice for a HFT shooter but also a great choice for a shooter looking to come in at a budget in the rimfire PRL league.

Design for precision shooters

The EVX Gen II model expands on the dependable and consistent reputation established by our EVX line during its 15+ years of service. It has been meticulously crafted to deliver sub-MOA accuracy for precision shooting and has undergone rigorous field testing to ensure it can withstand muzzle velocities of up to 6000j post-barrel. With its Japanese optical system, this rifle scope delivers exceptional high-resolution imaging at high magnification levels, while still providing shooters with a comfortable eye box.

Stainless steel tactical turret

The distinguishing feature of the EVX scope is its stainless steel turret, which produces a distinct and audible clicking sound, providing shooters with clear feedback. The turret can be locked in place by pushing or pulling it, and resetting the zero is as easy as turning the coin-removable cap located on the top of the turret. Additionally, for those who wish to engrave their hold-over markings, an empty turret is included in the package.

In addition, all EVX scopes are now available in either MIL/MIL (10 MIL per turn) or MOA/MOA (20 MOA per turn), matching the turret/reticle configuration. Furthermore, the scope features a revamped mil-hash reticle that provides long-range holdover capabilities.

Springer Rated

EVX Gen II has undergone extensive testing by champion shooters for over a year, using a springer rifle. It has proven to be durable and reliable, making it suitable for use with centrefire rifles as well.

What comes in the box:

3” sunshade, Throw lever, Empty turret, Lens covers.

SPECIFICATION

• Magnification (High):  16X
• Magnification (Low):  4X
• Objective Diameter (mm):  44mm
• Outer dia. Objective (mm):  52mm
• FOV (min.mag(ft/100yds):  27.2
• FOV (max.mag(ft/100yds):  6.5
• Eye relief (in): 3.8'' - 3.5''
• Exit Pupil (Max mag. (mm): 2.75 mm
• Exit Pupil (min. mag. (mm): 11 mm
• Diopter Range (dpt): + /- 2.0
• Parallax Adjustment:  10yds - infinity
• Coating: Fully Multi-coated
• Tube Construction: One-piece tube, aircraft
• Elevation Adjustment (value per click): 0.1 mrad
• Windage Adjustment (value per click): 0.1 mrad
• Turret Style (Elevation): Lock able Target Turret
• Turret Style (Windage): Lock able Target Turret
• Length (mm): 351 mm
• Weight (oz): 26.38oz
