Optisan CP 4-16x40 SFP Non Illuminated MRAD-MH10 Scope

DESCRIPTION

Brand new to the Optisan CP range of riflescopes is the Optisan CP 4-16x40 SFP. This is a second focal plane-based rifle scope equipped with an MH10 non-illuminated reticle.

The second focal plane reticle gives adequate holdover markings for most air rifle shooting disciplines including HFT and general hunting applications.

The Optisan CP range of riflescopes has always been a fan favourite in the HFT world thanks to its compact design and small objective lens sizes which allows the shooter to mount the rifle scope closer to the barrel to help with bullet trajectories.

The Optisan CP, like every other CP within the range, has parallax adjustments down to 10 yds and out to infinity. The Optisan CP 4-16x40 is a 30mm main tube which is made from one-piece aircraft-grade aluminium, with a length of 268mm and weighs only 530 grams, making it great for hunting out in the field and vermin control.

Compact design
At just 25.4 cm long and weighing less than 0.48 kg, the CP is the ideal companion for compact and lightweight rifles.

Minimized Parallax error

Equipped with a 32mm objective lens, the CP effectively reduces the impact of Parallax error, resulting in minimal shift of impact as you change your head position or distance to target.

This means you can shoot targets at various distances without experiencing any shift in point of impact, making it a valuable asset in competitive shooting scenarios.

Additionally, the parallax adjustment range of the CP ranges from 10 yards up to 500 yards to infinity, ensuring optimal performance across varying shooting distances.

Springer Rated
Champion shooters have field-tested this rugged riflescope for over a year on a springer rifle, proving its ability to withstand double direction recoil of up to 6000j post-barrel muzzle velocity. It’s not just limited to air rifles, as it’s also designed to hold centerfire firearms with ease.

Sleek Design with Extremely low-profile turret
All stainless steel extremely low-profile turret with 10 MRAD of adjustment per turn. No obstruction of view even when the night vision eyepiece is attached.

What comes in the box
2.5” sunshade, Lens covers.

SPECIFICATION

• Magnification (High):  16X ±5%
• Magnification (Low):  4X ±5%
• Objective Diameter (mm):  40mm
• Outer dia. Objective (mm):  48mm
• FOV (min.mag(ft/100yds):  26.20
• FOV (max.mag(ft/100yds):  6.55
• Eye relief (in): 3.5'' - 3.3''
• Exit Pupil (Max mag. (mm): 10 mm
• Exit Pupil (min. mag. (mm): 2.5mm
• Diopter Range (dpt): + /- 2.0
• Parallax Adjustment:  10yds - infinity
• Coating: Fully Multi-coated
• Tube Construction: One-piece tube, aircraft
• Elevation Adjustment (value per click): 0.1 mrad
• Windage Adjustment (value per click): 0.1 mrad
• Turret Style (Elevation): Low-profile, Zero-resettable
• Turret Style (Windage): Low-profile, Zero-resettable
• Length (mm): 268 mm
• Weight (g): 18.69 oz
