HIKMICRO EXPLORER E20 Smartphone Clip-In Thermal Imager for Android

DESCRIPTION

The HIKMICRO EXPLORER E20 Clip-In Thermal Imager is a radically small, versatile, and powerful device. It slots straight into any Android phone or tablet that has a USB Type C socket and transforms the way the user can see the world - and at the very low price of £329.99.

Weighing in at just 26 grams and measuring under 27mm in each dimension, the EXPLORER requires no batteries, drawing only minimal power from the smartphone or tablet. It can be carried easily, ready for near-instant use for spotting birds, animals, people (or indeed any other heat source) in any lighting conditions, including full darkness.

Fitted with a 256x192 thermal sensor and 10mm focal length lens system, the EXPLORER delivers similar thermal performance levels to the best-selling HIKMICRO Lynx 10mm monocular, allowing a good level of image detail and allows you to locate small animals and birds with ease.

The explorer is controlled by the HIKMICRO Sight app and you get access to the same features as the other HIKMICRO products including 4 colour palettes, digital zoom, and the ability to capture image and video.

Ultra-Portable Thermal Imaging – Weighs less than 26 g and smaller than a watch, making it easy to carry in your pocket for instant access.

Plug-and-Go Simplicity – Connects to compatible Android smartphones via USB Type-C for instant operation with the HIKMICRO Sight app.

High-Performance Thermal Detector – 256 × 192 resolution, 12 µm VOx sensor with a 9.7 mm lens delivers crisp heat signatures and fine detail.

Wide Field of View & Long Detection Range – 18.1° × 13.6° FOV for easy scanning and detection distances up to 970 m.

Six Viewing Modes Including Birdwatching – Choose from Birdwatching, Red Hot, White Hot, Black Hot, Rainbow, or Ironbow to suit your environment.

Advanced Observation Tools – Picture-in-picture, hot track, digital compass, and built-in video and snapshot recording enhance versatility.

• Image Sensor: VOx Uncooled Focal Plane Arrays
• Max. Resolution: 256 × 192
• Frame Rate: 50 Hz
• Pixel Interval: 12 μm
• Response Waveband: 8 μm to 14 μm
• NETD: Less than 50 mK (@25°C, F#=1.0)
• Lens (Focal Length): 9.7 mm
• Detection Range: 970 m
• Field of View (H × V), Degrees / m @100m: 18.1° × 13.6° / 31.8 m × 23.8 m
• Aperture: F1.0
• Magnification: 1×–2× (Digital zoom 2×)
• Image Display – Contrast Adjustment: Adjustable from 0 to 100 by slider control
• Image Display – Brightness Adjustment: Adjustable from 0 to 100 by slider control
• Image Mode: Birdwatching / Red Hot / White Hot / Black Hot / Rainbow / Ironbow
• General – Power Consumption: 360 mW
• General – Protection Level: IP40
• General – Weight: 26 g
• General – Dimension: 26.6 mm × 26.6 mm × 27.2 mm
• General – Working Temperature: From -10 °C to 50 °C
• General – Power Supply: USB Type-C interface
• System – Record Video: Yes
• System – Capture Snapshot: Yes
• System – Digital Magnetic Compass: Yes
• System – PIP: Yes
• System – Hot Track: Yes
