NiteSite
NS200
NiteSite
is an innovative and unconventional way of shooting, in that
you do not have your three points of contact to take a shot!
You simply shoulder the rifle in a ‘heads up’ position
viewing the cross-hairs of your day scope on the LCD screen
mounted on the top of the scope! The NiteSite system has an
infra-red camera that fits to a regular day scope using a flexible
sleeve. Once the camera is put in place and connected to the
LCD screen and illuminator module, the image of the cross-hairs
is clearly visible on the LCD screen! It is that simple!
The LCD
screen and illuminator module has an infra red beam that is
switched in four increments from off to full by turning the
switch on top of the illuminator unit. The infra red camera
module can see the infra red light very clearly. This method
of night vision can give a recognisable image up to a distance
of 200 yards with the NS200 model, and in excess of 50 yards
for the NS50 model. This will depend on the quality of the day
scope optics that are in use at the time.
NiteSite
is a very easy way to achieve night vision for your day scope
rifle combo. There is no need to remove your day scope for this
system, there is no need for re-sighting your day scope recalibrating
any part of your set-up for this system, it is a very easy plug
and play system that will convert your day set up into a night
vision set up in just a couple of minutes.
These product
are manufactured in the United Kingdom.
The camera
module is a colour sony 1/3 ccd 0.01 lux. This will give a clear
field of view depending on your scope optics up to 200 yards/meters.
Both camera modules give a 4 by 3 ratio screen image ideal for
a round or spherical optic
The LCD
screens are all colour 3 inch screens.
The black
lens cover is an infra-red filter which allows the infra-red
light to pass through it and protects the LEDs and optics.
The illuminator
has 4 powerful infra-red LEDs with separate optics giving a
beam angle of 3 degrees.
The kit
contains a 12v battery charger which will fully charge the battery
in 6-7 hours from flat. The camera module, screen and illuminator
module are showerproof. There are heat dissipation vents on
the underside of the main screen and illuminator body. The camera
body and the illuminator body are made from ABS, which is a
tough durable plastic.
The rubber
camera mounting tubes come in 2 sizes to enable fitting to most
scopes. There are two clamps that sit both sides of the scope
tubes (1 inch and 30mm). They are made from polypropolene which
enables them to slip over standard size scope sleeves easily
and have a plastic knurled thumb screw to fasten the screen
and illuminator body to.
The battery
is a 12v 3.3amp SLA (sealed lead acid battery) and comes with
a fused power lead. The battery pouch is made from a tough nylon
with a belt loop and velcro flap.
This kit
includes
* 1 x Colour
camera module (NS200 only)
* 2 x rubber sleeve
* 2 x scope clamp (1 x 1 inch 1 x 30mm)
* 1 x LCD screen & Infrared illuminator
* 1 x 3.3amp battery with bag and cables
* 1 x battery charger
* 1 x carry case
* 1 x instruction leaflet
* one years warranty
